DRILLING Indexable inserts

DEX Self-locking drilling head ISO513 HC-PVD JP7625
JP5625

DC tol. SIG P 40 TURNING
160
k6 140° M
K 80 100
180 200
N
S

H
GRADE APPLICATION AREA Stable machining d d
d
d
d
d
d main application General machining | Hardness + + Toughness | d d THREADING
d
d
d applicable Unstable machining d d
GP P K DC 17.60 DEX1760-GP PL 3.20 f n£ 0.20 0.28 0.36 h
DC 17.70 DEX1770-GP PL 3.22 f n£ 0.20 0.28 0.36 h
DC 17.80 DEX1780-GP PL 3.24 f n£ 0.20 0.28 0.36 h

DC 17.90 DEX1790-GP PL 3.26 f n£ 0.20 0.28 0.36 h
DC 18.00 DEX1800-GP PL 3.28 f n£ 0.22 0.30 0.40 h GROOVING
DC 18.10 DEX1810-GP PL 3.29 f n£ 0.22 0.30 0.40 h
DC 18.20 DEX1820-GP PL 3.31 f n£ 0.22 0.30 0.40 h
DC 18.30 DEX1830-GP PL 3.33 f n£ 0.22 0.30 0.40 h
DC 18.40 DEX1840-GP PL 3.35 f n£ 0.22 0.30 0.40 h
DC 18.50 DEX1850-GP PL 3.37 f n£ 0.22 0.30 0.40 h

DC 18.60 DEX1860-GP PL 3.38 f n£ 0.22 0.30 0.40 h
DC 18.70 DEX1870-GP PL 3.40 f n£ 0.22 0.30 0.40 h MILLING
DC 18.80 DEX1880-GP PL 3.42 f n£ 0.22 0.30 0.40 h
GENERAL DC 18.90 DEX1890-GP PL 3.44 f n£ 0.22 0.30 0.40 h

DC 19.00 DEX1900-GP
PL 3.46 f n£ 0.24 0.32 0.42 h
DC 19.10 DEX1910-GP PL 3.48 f n£ 0.24 0.32 0.42 h
DC 19.20 DEX1920-GP PL 3.49 f n£ 0.24 0.32 0.42 h
DC 19.30 DEX1930-GP PL 3.51 f n£ 0.24 0.32 0.42 h
DRILLING
DC 19.40 DEX1940-GP PL 3.53 f n£ 0.24 0.32 0.42 h
DC 19.50 DEX1950-GP PL 3.55 f n£ 0.24 0.32 0.42 h
DC 19.60 DEX1960-GP PL 3.57 f n£ 0.24 0.32 0.42 h
DC 19.70 DEX1970-GP PL 3.59 f n£ 0.24 0.32 0.42 h
DC 19.80 DEX1980-GP PL 3.60 f n£ 0.24 0.32 0.42 h
DC 19.90 DEX1990-GP PL 3.62 f n£ 0.24 0.32 0.42 h
DC 20.00 DEX2000-GP PL 3.64 f n£ 0.26 0.35 0.44 h
ACCESSORIES
DC 20.10 DEX2010-GP PL 3.66 f n£ 0.26 0.35 0.44 h

DC 20.20 DEX2020-GP PL 3.68 f n£ 0.26 0.35 0.44 h
DC 20.30 DEX2030-GP PL 3.69 f n£ 0.26 0.35 0.44 h
h stock standard
£
