DRILLING Holders

TURNING DC DCON

LB
LF
OAL

DRS Pilot 6xD DC DCON OAL LF LB A (insert) (pilot)
MIID
MIID
THREADING 05 NT-DRS-6D D18.00-S25-05P6 h 18 25 191 135 112 SPMX05 DRSP06

NT-DRS-6D D19.00-S25-05P6 h 19 25 197 141 118 SPGX05
D20.00-S25-06P6
h
124
25
20
203
147
D21.00-S25-06P6 h 21 25 209 153 130
D22.00-S25-06P6 h 22 25 215 159 136 SPMX06
06 DRSP06
D23.00-S32-06P6 h 23 32 228 168 142 SPGX06
D24.00-S32-06P6 h 24 32 234 174 148
D25.00-S32-06P6 h 25 32 240 180 154
NT-DRS-6D D26.00-S32-07P8 h 26 32 246 186 160
GROOVING 07 D27.00-S32-07P8 h 27 32 252 192 166 SPMX07 DRSP08
D28.00-S32-07P8
198
28
h
258
32
172
D29.00-S32-07P8 h 29 32 264 204 178 SPGX07
D30.00-S32-07P8 h 30 32 270 210 184
h stock standard
INSERT SCREW INSERT WRENCH LOCKING GRAIN SETTING GRAIN GRAIN WRENCH
Spare Parts Spare Parts
MILLING NT-DRS-6D D.-S-05P6 NT-ST059 NT-FTB06 DC 18÷22 NT-ST042 NT-ST043
NT-DRS-6D D.-S-06P6 NT-ST061 NT-FTB06 DC 23÷25 NT-ST044 NT-ST045 NT-WR025
NT-DRS-6D D.-S-07P8 NT-ST062 NT-FTB07 DC 26÷30 NT-ST046 NT-ST047 NT-WR030
