MILLING Holders
ARBOR DCON FACING
45°
INTERNAL P M K TURNING
COOLANT LF
NS H
KAPR
DC
DCX
Double4Face
DC DCX S DCON LF A MIID
Facing (KAPR 45°) THREADING
NT-SX12H D050-F22-Z4 h 4 22 40 0.60
50 64
D050-F22-Z5 h 5 22 40 0.60
D063-F22-Z5 h 5 22 50 0.80
63 77
D063-F22-Z6 h 6 22 50 0.80
D080-F27-Z6 h 6 27 50 1.40
ARBOR D080-F27-Z7 h 80 94 7 8 27 50 1.40 SNMX12
SNEX12
D080-F27-Z8
h
1.40
50
27
D100-F32-Z7 h 7 32 50 1.80
D100-F32-Z8 h 100 114 8 32 50 1.80
D100-F32-Z9 h 9 32 50 1.80 GROOVING
D125-F40-Z10 h 125 139 10 40 63 3.10
D160-F40-Z12 h 160 174 12 40 63 4.60
h stock standard
SHIM SHIM SCREW SHIM WRENCH INSERT SCREW INSERT WRENCH
Spare Parts
MILLING
NT-SX12H D NT-SH009 NT-SR009 NT-WR040 NT-ST029 NT-FTB15
DRILLING
ACCESSORIES
